Origami-inspired robot combines precision with speed

milliDelta robot next to penny

Science & Technology

Origami-inspired robot combines precision with speed

Completely unfolded, the milliDelta roughly compares to a cent piece, and can perform movements at frequencies 15 to 20 times higher than those of other currently available Delta robots.

Credit: Wyss Institute at Harvard University

The milliDelta opens new avenues for microsurgery, microassembly, and micromanipulation

Because of their high precision and speed, Delta robots are deployed in many industrial processes, including pick-and-place assemblies, machining, welding, and food packaging. Starting with the first version Reymond Clavel developed for a chocolate factory to quickly place chocolate pralines in their packages, Delta robots use three individually controlled and lightweight arms that guide a platform to move fast and accurately in three directions. The platform is either used as a stage, similar to the ones used in flight simulators, or coupled to a manipulating device that can, for example, grasp, move, and release objects in prescribed patterns. Over time, roboticists have designed smaller and smaller Delta robots for tasks in limited workspaces, yet shrinking them further to the millimeter scale with conventional manufacturing techniques and components has proven fruitless.

Reported in Science Robotics, a new design, the milliDelta robot, developed by Robert Wood’s team at Harvard’s Wyss Institute for Biologically Inspired Engineering and John A. Paulson School of Engineering and Applied Sciences (SEAS), overcomes this miniaturization challenge. By integrating their microfabrication technique with high-performance composite materials that can incorporate flexural joints and bending actuators, the milliDelta can operate with high speed, force, and micrometer precision, which together make it compatible with a range of micromanipulation tasks in manufacturing and medicine.

In 2011, inspired by pop-up books and origami, Wood’s team developed a micro-fabrication approach that enabled the assembly of robots from flat sheets of composite materials. Pop-up MEMS (short for microelectromechanical systems) manufacturing has been used since then to build dynamic centimeter-scale machines that can simply walk away, or, as in the case of the RoboBee, fly. In their new study, the researchers applied their approach to develop a Delta robot measuring a mere 15-by-15-by 20 mm.


Onward and upward, robots

Harvard scientists help drive new age of machines, aiming for transformative impact in medicine, on Main Street, and beyond

From drinking straws to robots

Harvard scientists use simple materials to create semi-soft machines that walk like insects

Soft robot helps the heart beat

Sleeve attaches directly around the heart

“The physics of scaling told us that bringing down the size of Delta robots would increase their speed and acceleration, and pop-up MEMS manufacturing, with its ability to use any material or combination of materials, seemed an ideal way to attack this problem,” said Wood, who is a core faculty member at the Wyss Institute and co-leader of its Bioinspired Robotics platform, and the Charles River Professor of Engineering and Applied Sciences at SEAS. “This approach also allowed us to rapidly go through a number of iterations that led us to the final milliDelta.”

This video briefly explains how the milliDelta robot is built and how it works.

Credit: Wyss Institute at Harvard University

The milliDelta design incorporates a composite laminate structure with embedded flexural joints that approximate the more complicated joints found in large-scale Delta robots. “With the help of an assembly jig, this laminate can be precisely folded into a millimeter-scale Delta robot. The milliDelta also utilizes piezoelectric actuators, which allow it to perform movements at frequencies 15 to 20 times higher than those of other currently available Delta robots,” said first author Hayley McClintock, a Wyss Institute Staff researcher on Wood’s team.

In addition, the team demonstrated that the milliDelta can operate in a workspace of about 7 cubic millimeters and that it can apply forces and exhibit trajectories that, together with its high frequencies, could make it ideal for micromanipulations in industrial pick-and-place processes and microscopic surgeries such as retinal microsurgeries performed on the human eye.

Putting the milliDelta’s potential for microsurgeries and other micromanipulations to a first test, the researchers explored their robot as a hand tremor-canceling device. “We first mapped the paths that the tip of a toothpick circumscribed when held by an individual, computed those, and fed them into the milliDelta robot, which was able to match and cancel them out,” said co-first author Fatma Zeynep Temel, a postdoctoral fellow in Wood’s team. The researchers think that specialized milliDelta robots could either be added on to existing robotic devices, or be developed as standalone devices such as platforms for the manipulation of cells in research and clinical laboratories.

Other authors on the study are SEAS graduate student Neel Doshi and Je-sung Koh, a former postdoctoral fellow on Wood’s Wyss Institute/SEAS team and now assistant professor at Ajou University in Korea. The work was funded by Harvard’s Wyss Institute for Biologically Inspired Engineering and a National Defense Science and Engineering Graduate Fellowship.
